WQ Series

  • Easy installation thanks to 10m power cable with plug.

  • Automatic operation through tethered float switch.

  • Operationally safe thanks to self-switching thermal motor monitoring.


WQ Series
Product Selection Series Description Documents
Number of results: 15
Product descriptionOutput powerSolids handlingDischarge
50WQ0.37-2P0.37 kw38 mmG 2.0"FPDF
50WQ0.55-2P0.55 kw38 mmG 2.0"FPDF
50WQ0.75-2P0.75 kw38 mmG 2.0"FPDF
50WQ0.37-4P0.37 kw38 mmG 2.0"FPDF
50WQ0.55-4P0.55 kw38 mmG 2.0"FPDF
50WQ0.75-4P0.75 kw38 mmG 2.0"FPDF
80WQ0.37-4P0.37 kw50 mmG 3.0"FPDF
80WQ0.55-4P0.55 kw50 mmG 3.0"FPDF
80WQ0.75-4P0.75 kw50 mmG 3.0"FPDF
80WQ1.1-4P1.10 kw50 mmG 3.0"FPDF
80WQ1.5-4P1.50 kw50 mmG 3.0"FPDF
80WQ2.2-4P2.20 kw50 mmG 3.0"FPDF
100WQ1.5-4P1.50 kw45 mmG 4.0"FPDF
100WQ2.2-4P2.20 kw45 mmG 4.0"FPDF
100WQ3.7-4P3.70 kw45 mmG 4.0"FPDF


Series Description

  • WQ Series
    WQ Series
  • WQ Series
    WQ Series
  • WQ Series
    WQ Series
  • WQ Series
  • WQ Series
  • WQ Series

Design

Submersible sewage pump for transportable installation


Application

Drainage of

  • Pump chamber and pump sump

  • Soakaway

  • Flooded basements


Liquid

For the pumping in household areas of:

  • Sewage without faeces

  • Wastewater (with small amounts of sand and gravel)


Materials

  • Motor housing: GG20

  • Pump housing (volute): GG20

  • Impeller: GG20


Specifications

  • Liquid temperature:104°F (40°C) continuous

  • Motor: B insulation class, IP68 protection

  • Single phase: Build in thermal protector

  • Accessories: Float switch is available


Sewage Series

Sewage Series
